Gigabyte B550M GAMING X WIFI6 Motherboard
  • Model:B550M GAMING X WIFI6
  • Supports AMD Ryzen 5000/4000/3000 CPUs
  • AMD B550 chipset, Socket AM4, Micro-ATX
  • Dual Channel DDR4, 4 DIMMs
  • PCIe 4.0, 2x M.2, WiFi 6, USB 3.2
  • 3 Years Warranty from Gigabyte
₹ 10,100
Next Day Dispatch
1
CPU
AMD Ryzen™ 5000 Series/ 3rd Gen Ryzen™/ 3rd Gen Ryzen™ with Radeon™ Graphics/ 2nd Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Graphics Processors (Socket AM4)
Chipset
AMD B550
Memory Type
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Memory Speed
Support for DDR4 4733(O.C.)/ 4600(O.C.)/ 4400(O.C.)/ 4266(O.C.)/ 4000(O.C.)/ 3866(O.C.)/ 3733(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3200/ 2933/ 2667/ 2400/ 2133 MHz memory modules
ECC Support
Support for ECC un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
XMP Support
Support for Extreme Memory Profile (XMP) memory modules
Integrated Graphics Processor
1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
Audio
Realtek® Audio CODECHigh Definition Audio2/4/5.1/7.1-channel
LAN
Realtek® GbE LAN chip (10/100/1000 Mbit)
Wireless Communication module
Intel® Wi-Fi 6 AX200Supports 802.11 a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-BandBLUETOOTH 5.1
Expansion Slots
1 x PCI Express x16 slot, running at x16 (PCIEX16) (PCI Express 4.0, only supported when using a 3rd Gen AMD Ryzen™ or above CPU.)1 x PCI Express x16 slot, running at x4 (PCIEX4) (PCI Express 3.0)1 x PCI Express x1 slot (PCI Express 3.0)
Storage Interface
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA & PCIe 4.0 x4/x2 SSD support)1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA & PCIe 3.0 x4/x2 SSD support)4 x SATA 6Gb/s connectors
RAID Support
RAID 0, RAID 1, and RAID 10 support for SATA storage devices
USB
Rear: 1 x USB Type-C® port, with USB 3.2 Gen 2 support (red)3 x USB 3.2 Gen 1 ports (blue)2 x USB 2.0/1.1 portsInternal: 1 x USB 3.2 Gen 1 header (supports 2 additional USB ports)2 x USB 2.0/1.1 headers (supports 4 additional USB ports)
Internal I/O Connectors
1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header2 x system fan headers1 x CPU_OPT fan header1 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x speaker header1 x USB 3.2 Gen 1 header2 x USB 2.0/1.1 headers1 x RGB LED strip header1 x addressable LED strip header1 x Clear CMOS jumper1 x Trusted Platform Module (TPM) header1 x chassis intrusion header
Back Panel Connectors
1 x PS/2 keyboard/mouse port1 x DVI-D port1 x HDMI port1 x USB Type-C® port, with USB 3.2 Gen 2 support3 x USB 3.2 Gen 1 ports2 x USB 2.0/1.1 ports1 x RJ-45 port3 x audio jacks
Form Factor
Micro ATX Form Factor; 24.4cm x 24.4cm
Operating System
Support for Windows 11 64-bit, Windows 10 64-bit
