- Model:VCNRTX6000ADA
- 48GB GDDR6 memory with ECC
- 18,176 CUDA cores, NVIDIA Ada Lovelace architecture
- 4x DisplayPort 1.4a, PCIe 4.0 x16
- 300W, dual slot, 4.4" H x 10.5" L
- 3 Years Warranty from PNY
Overview
The NVIDIA RTX 6000 Ada Generation is the ultimate workstation graphics card designed for professionals who demand maximum performance and reliability. Built on the NVIDIA Ada Lovelace architecture, it features 142 third-generation RT Cores, 568 fourth-generation Tensor Cores, and 18,176 CUDA cores with 48GB of error correction code (ECC) graphics memory.
This card delivers unmatched performance for high-end design, real-time rendering, AI, and high-performance compute workflows. With 2X the speed of the previous generation for single-precision floating-point operations, it provides significant performance improvements for graphics and simulation workflows such as complex 3D CAD and CAE. The third-generation RT Cores deliver up to 2X the throughput for photorealistic rendering, architectural design evaluations, and virtual prototyping.
The RTX 6000 Ada supports up to four 5K monitors at 60Hz or dual 8K displays at 60Hz per card, with DisplayPort 1.4a connectors and support for NVIDIA Mosaic technology to scale the desktop across up to 4 GPUs and 16 displays. It includes virtualization-ready support for NVIDIA RTX Virtual Workstation software and eighth-generation dedicated hardware encoder with AV1 encoding for streaming and video conferencing.
- NVIDIA Ada Lovelace Architecture
- 48GB GDDR6 with ECC
- 18,176 CUDA Cores
- 568 Fourth-Generation Tensor Cores
- 142 Third-Generation RT Cores
- 4x DisplayPort 1.4a
- 300W Max Power Consumption
- Dual-Slot, Full Height Form Factor
- NVIDIA Mosaic Technology Support
- AV1 Encoders
Specifications
- PNY Part Number
- Retail: VCNRTX6000ADA-PBSingle Bulk: VCNRTX6000ADA-SBBulk: VCNRTX6000ADA-BLKEducation: VCNRTX6000ADA-EDU
- GPU memory
- 48GB GDDR6
- Memory interface
- 384-bit
- Memory bandwidth
- 960 GB/s
- Error correction code(ECC)
- Yes
- NVIDIA Ada Lovelace architecture-based CUDA Cores
- 18,176
- NVIDIA third-generation Tensor Cores
- 568
- NVIDIA second-generation RT Cores
- 142
- Single-precision performance
- 91.1 TFLOPS3
- RT Core performance
- 210.6 TFLOPS3
- Tensor performance
- 1457.0 TFLOPS4
- System interface
- PCIe 4.0 x16
- Power consumption
- Total board power:300W
- Thermal solution
- Active
- Form factor
- 4.4"Hx10.5"L, dual slot, full height
- Display connectors
- 4x DisplayPort 1.4a5
- Max simultaneous displays
- >4x4096x2160@120Hz>4x5120x2880@60Hz>2x7680x4320@60Hz
- Power connector
- 1x PCIe CEM5 16-pin
- Encode/decode engines
- 3x encode,3x decode(+AV1 encode and decode)
- VR ready
- Yes
- vGPU software support5
- >NVIDIA vPC/vApps>NVIDIA RTX Virtual Workstation
- vGPU profiles supported
- See theVirtual GPU Licensing Guide
- Graphics APIs
- DirectX 12, Shader Model 6.6, OpenGL 4.66,Vulkan 1.36
- Compute APIs
- CUDA 11.6,OpenCL 3.0,DirectCompute
- NVIDIA NVLink®
- No
Warranty
3 Years manufacturer warranty from PNY. Warranty service is provided by the brand's authorised service centre under the brand's own terms; keep the original invoice and the serial number for any claim, and we will guide you through the process. Details are in our Warranty Policy.
