- Model:VCNT10008GB-LLP
- 8GB GDDR6 memory
- 896 CUDA cores, NVIDIA Turing architecture
- 4x Mini DisplayPort 1.4, PCIe 3.0 x16
- 50W, single slot, 2.713" H x 6.137" L
- 3 Years Warranty from PNY
Overview
The NVIDIA T1000E, built on the NVIDIA Turing GPU architecture, is a powerful, low-profile solution that delivers full-size features, performance and capabilities required by demanding professional applications in a compact graphics card. Featuring 896 CUDA cores and 8GB of GDDR6 memory, the T1000E enables professionals to tackle multi-app workflows, from 3D modeling to video editing.
The Turing GPU architecture includes advanced shader technologies: Mesh Shading speeds up geometry processing, offering up to 2x performance. Variable Rate Shading enhances efficiency by adjusting shading rates, cutting shaded pixels by 50%. Texture Space Shading boosts performance in pixel shader-heavy tasks like depth-of-field. The card features 160 GB/s of peak bandwidth for double the throughput of the previous generation.
The NVIDIA T1000E includes H.264 and HEVC encode and decode engines independent of the 3D/compute pipeline, delivering faster than real-time performance for transcoding and video editing. Support for up to four 5K displays gives an expansive visual workspace. The card is part of the PNY Long Life Program with product availability through December 2029.
- NVIDIA Turing Architecture
- 896 CUDA Cores
- 8GB GDDR6 memory with 160 GB/s bandwidth
- 4x Mini DisplayPort 1.4 with latching mechanism
- 50W max power consumption, single slot
- H.264 and HEVC encode/decode engines
- NVIDIA GPU Boost 4.0
- Compute and Graphics Preemption
Specifications
- PNY Part Number
- VCNT10008GB-LLP
- GPU memory
- 8GB GDDR6
- Memory Interface
- 128-bit
- Memory Bandwidth
- Up to 160 GB/s
- NVIDIA® CUDA® Cores
- 896
- System Interface
- PCIe 3.0 x 16
- Power Consumption
- 50 W
- Thermal Solution
- Active
- Form factor
- 2.713 inches H x 6.137 inches L, single slot
- Display Connectors
- 4 x mDP 1.4 with latching mechanism
- Max Simultaneous Displays
- 4x 3840 x 2160 @ 120Hz 4x 5120 x 2880 @ 60Hz 2x 7680 x 4320 @ 60Hz
- Graphics APIs
- DirectX 12 Ultimate, Shader Model 6.6, OpenGL 4.64, Vulkan 1.34
- Compute APIs
- CUDA 11.6, DirectCompute, OpenCL 3.0
Warranty
3 Years manufacturer warranty from PNY. Warranty service is provided by the brand's authorised service centre under the brand's own terms; keep the original invoice and the serial number for any claim, and we will guide you through the process. Details are in our Warranty Policy.
